VPC27-W53-O1-1B

Dimension: M.2 2280 (22 x 80 mm)
Capacité: 256GB SSD
Interface: M.2 2280 NVMe PCIe Gen3 SSD

MIC(Microphone): x1

DisplayPort: x 1 (1.4, resolution 3840x2160@60Hz)
HDMI: x 1 (1.4, resolution 3840x2160@60Hz)
Audio: x 1 Line out

RJ45: GbE LAN Port

Intel AX200 WiFi 6 + BT5.2 Module dual band

Type A: USB x 4 (USB 3.2 x 1, USB 2.0 x 3)
Type C: x 1 (data only)

Adobe Reader /
myViewBoard WhiteBoard /
WatchDog /
Winflash

Tension: DC in +12V~+19V @ 3.42A
Consommation: 65 W (Typical)

Température (º C): -5~45°C
Humidité: 20% ~ 80% R.H. Non-Condensing

Physique (pouces / mm): 7.95” x 4.69” x 1.18” / 202 x 119 x 30 mm
Emballage (pouces / mm): 10.00” x 7.72” x 3.03”/254 x 196 x 77 mm

Net (lb / kg): 2.205 lb/1 kg
Brut (lb / kg): 2.646 lb/1.2 kg

1. VPC OPS
2. Quick Start Guide
3. Screw x 2

*The Windows 11 upgrade will be delivered to qualifying devices late 2021 into 2022. Timing varies by device. Certain features require specific hardware. (see Windows 11 Specifications https://www.microsoft.com/en-us/windows/windows-11-specifications?r=1)
