LSC600-4K

6,000 ANSI Lumens 4K Laser Installation Projector

  • 4K HDR professional-quality visuals
  • 6,000 ANSI Lumens offering bright images in any environment
  • Up to a 300" ultra-large screen with a lower cost-per-inch
  • Supports a 21:9 aspect ratio, ideal for Microsoft Teams Rooms
  • Installation flexibility: H/V lens shift, 1.6x optical zoom, and H/V keystone correction
  • 2nd generation laser phosphor technology with a lifespan up to 30,000 hours
  • Centralized LAN control for efficient management

SPECIFICATIONS


  • Specification
    Projection System: 3LCD (3x0.64" with MLA)
    Native Resolution: WUXGA with 4K Enhancement
    Brightness: 6000 (ANSI Lumens)
    Brightness (Center Lumens): 6500
    Contrast Ratio: 3000000:1
    Display Color: 1.07 Billion Colors
    Light Source Type: Laser Phosphor
    Light Source Life (hours) with Normal Mode: 20000
    Light Source Life (hours) with SuperEco Mode: 30000 (Eco)
    Lens: F=1.5-2.08, f=17.2-27.7mm
    Projection Offset: 0%+/-5%
    Throw Ratio: 1.2-2.0
    Optical Zoom: 1.6X
    Digital Zoom: 1.0x-2.0x
    Image Size: 30"-300"
    Throw Distance: 0.80-13.35m
    (100"@2.66m)
    Keystone: H:+/-25° , V:+/-30°
    Auto Keystone: +/- 30° (V)
    Lens Shift V. Range: +66%, 0%
    Lens Shift H. Range: +29%, -29%
    Audible Noise (Normal): 37dB
    Audible Noise (Eco) : 26dB
    Input Lag: 32ms
    Resolution Support: VGA(640 x 480) to 4K(3840 x 2160)
    HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
    Horizontal Frequency: 15K-135KHz
    Vertical Scan Rate: 24-85Hz
  • Input
    HDMI: 2
    (HDMI 2.0, HDCP 1.4/2.2)
    Audio-in (3.5mm): 1
    USB Type A: 2 (5V/2A)
    RJ45 Input (Internet): Yes
  • Output
    Audio-out (3.5mm): 1
    Audio-out (HDMI ARC): 1
    (share with HDMI Input)
    S/PDIF: 1
    Speaker: 16W
    USB Type A (Power): 2
    (USB2.0 - 5V/2A,
    share with USB A Input)
