ViewBoard
IFP6560-vsi
Főbb Tulajdonságok
Termék leírás
The ViewBoard® IFP6560 is an 65” 4K (3840 x 2160) interactive flat panel display with an open platform design and diverse collaborative capabilities. ViewBoard® IFP6560 is fit for integration into Google-based environments, offers seamless Windows accessories & office365 compatibility, comes equipped with Mac multi-touch gesture mirroring, and supports Linux PC touch back remote control. InGlass™ technology delivers a more accurate and sleek touchscreen experience with lag-free writing and drawing in two colors with different thicknesses. Pairing ViewBoard® IFP6560’s 20-point touch display with pre-installed tools, such as vBoard for annotation, ViewBoard® Cast for content sharing, and Zoom conference software, allows multiple users to remotely write, share, and interact simultaneously. Connecting to more powerful computing platforms is possible via the board’s PC slots for the optional Intel certified OPS (Open Pluggable Specification) which allows users to switch their system to Windows OS. Connecting to the board is made easy through SmartPort™ shared front USB ports for internal and external PCs. Finger print recognition bolsters security and enables easy login to Windows or myViewBoard™ for your digital whiteboad in the cloud. Versatile connectivity to a multitude of devices combined with VESA-compatibility and a trolley design allows for flexible installation anywhere, no matter the occasion.
Látogasson el hozzánk
- www.viewsonic.com
-
LCD PANEL
Panel mérete: 65" Típus/ Technika: TFT LCD Module with DLED Backlight Megjelenített terület (mm): 1428.48(H) x 803.52(V) mm (64.5” diagonal) Képarány: 16:9 Felbontás: 3840 x 2160 Colors: 1.07B (8Bit+FRC) Fényerő: 350 nits (typ.) Kontrasztarány: 4000:1 (typ.) Válaszidő: 8 ms Betekintési szögek: H = 178, V = 178 (typ.) Backlight: DLED Háttérvilágítás élettartama: 30,000 Hours Min. Hardness: 7H -
TOUCH
Típus/ Technika: Flatfrog InGlass IR Érintés felbontás: 22855 x 12856 Touch Point: 20 points touch, 10 points writing Válaszidő: 6.7ms System: Win 7pro/Ultimate/8/8.1/10, Chrome OS Linux kernel 3.15 or later, Android 4.4 with linux kernel 3.15 or later, Linux OS kernel 3.15 or later, Mac OS 10.10 or later -
INPUT
HDMI: 1 x HDMI 1.4a, 4K@30Hz, support CEC on/off, HDCP 1.4
2 x HDMI 2.0, 4K@60Hz, support CEC on/off, HDCP 2.2RGB / VGA: x 1 DisplayPort: x 1 (4K@30Hz) Audió: x 1 PC audio (3.5mm) CVBS (AV): x 1 RS232: x 1 PC Slot: x 1 (Intel OPS) -
OUTPUT
HDMI: x 1 HDMI 2.0, 4K@60Hz, no CEC support Audio (Earphone out): x 1 SPDIF: x 1 RS232: x 1 -
LAN
RJ45: x 1 -
USB
2.0 Type A: x 3 (front x 2, for both embedded player and slot-in PC) 3.0 Type A: x 2 2.0 Type B (For touch): x 2 (front x 1 for HDMI 1.4; back side x 1 for HDMI2.0, DP, VGA) -
HANGSZÓRÓK
10W x 2 -
BUILT-IN PC
Processzor: ARM Cortex A53 Quad Core 1.4G Hz CPU Graphic: ARM Mali-450 MP4 Quad Core Memória: 2GB DDR3 Tárolás: 16GB eMMC Networking: 10/100M auto-identification and DHCP -
COMPATIBILITY
VGA: Refer to timing table HDMI: 3840x2160 DP: 3840x2160 -
POWER
Feszültség: 100V-240V,50/60Hz (AC) Fogyasztás: 210 W (without OPS)
270 W (With OPS) -
ERGONOMICS
Falra szerelhető (VESA® ): 600 x 400mm; Screw: M8 x 25mm -
OPERATING CONDITIONS
Hőmérséklet (ºC): 32°F to 104°F (0°C to 40°C) Páratartalom: 20% ~ 80% non-condensing -
DIMENSIONS (W X H X D)
Physical w/o Stand (mm / inch): 1565.5 x 967.1 x 94.5 mm / 61.63 x 38.07 x 3.72 inch Packaging (mm / inch): 1715 x 1100 x 280 mm / 67.52 x 40.31 x 11.02 inch -
WEIGHT
Net w/o Stand (kg / lb): 48.5kg/106.9lb Gross (kg / lb): 61kg/134.5lb -
WHAT'S IN THE BOX?
1. HDMI cable(1.5 meters)
2. Power cable(3 meters) x 4 (A+E+M+U)
3. Remote control with AA battery
4. USB cable(1.8 meters)
5. Touch pen x 2
6. Quick Start Guide & Compliance statement
7. Webcam Plate
8. Wall mount Screw x 4
