CDE4200-L

오디오: x1 Earphone Out
SPDIF: x1
IR 패스스루: thru RS232
리모컨 출력: x1

A형: x1

10W x 2

RGB PC/HDMI PC: Refer to timing table
CVBS: 480i,576i
YPbPr: 480i, 480p,720p, up to 1080p
HDMI: 480i, 480p,720p, up to 1080p

Physical- Top OSD: PICTURE: Picture Settings Picture Mode(Power Saving/Dynamic/Stander/Movie/User),
Screen Size ( Wide/Cinema/Zoom/Normal)
PC Settings
Color Temparature ( Normal/Warm/Cool)
Backlight (Medium/High/Low)
Advanced Picture Settings(Dynamic Contrast-Low/Medium/high/off; Film Mode-on/off; Noise Reduction-Low/Medium/high/off; MPEG Noise Reduction- low/Medium/high/off.
SOUND: Sound Setting( Standard/Soft/User/Dynamc),Analog Sound, Digital Sound, Digital Audio Output, Equalizer Setting.
PARENTAL: Lock Parent Control, V-CHIP,Change Password, Keypad Lock, Source Lock, System Lock.
SETUP: Closed Caption, Menu Language( English/French/Spanish/German/Portuguese), Clock, OSD Transparency, OSD Timer.
OTHERS: Blue Back, No Signal Power Off, No Operation Power Off, User Moniro, Audio Only, TV ID, All Reset.
Multimedia: PICTURE: JPG
AUDIO: MP3

전압: 100-240VAC +/- 10% 50/60Hz Wide Range
소비.: 59W (typ), 75 W (max)
< 0.5 W ("Off")

Wall Mount (VESA® ): 200 x 200

Temperature (º C): 0°C to 40°C
습도: 20% ~ 80% @40°C non-condensing

물리적(인치/mm): 38.35x24.66x 8.27 / 974.2 x 626.3 x 210 (w/ stand)
38.35x22.30x2.54 / 974.2 x 567.2 x 64.4 (w/o stand)
포장(inch/mm): 47.2 x 27.5 x 5.6 / 1200x 700x 143 (w/o stand)

순(lb/kg): 26.18 / 11.9 (w/o stand)
29.26 / 13.3 (with Stand)
총중량(파운드/kg): 35.42 / 16.1

1. CDE4200-L display 2. power cable 3. remote control with batteries 4.User Guide 5. Quick Start Guide

*Actual content may differ from market to market
