CDM5500T

55" 10-point Multi-touch Commercial Display

OUTPUT
디스플레이 포트: x 1
DVI: x 1
RS232: x 1
IR: x 1
LAN
RJ45: x 1
USB
A형: x 2 (Multi-media playback x 1, 5V/2A x 1)
B형: x 1 (Touch out)
마이크로 USB: x 1 (Support USB OTG)
AUDIO
스피커: 10W x 2
BUILT-IN PC
프로세서: Quad core A9, 1.6G
보관소: eMMC 16G
COMPATIBILITY
VGA: 480i, 480p,720p,1080i,1080p
DVI: 480i, 480p,720p,1080i,1080p
디스플레이 포트: 480i, 480p,720p,1080i,1080p, 4K2K@30Hz
HDMI: 480i, 480p,720p,1080i,1080p, 4K2K@30Hz
POWER
전압: 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz
소비.: Normal 76W, Max 143W
ERGONOMICS
Wall Mount (VESA® ): 400x400mm ; Screw: M6*(10+X) mm (X=thickness of wall mount plate)
OPERATING CONDITIONS
Temperature (º C): 0 to 40°C (Landscape)/0 to 35°C (Portrait)
습도: 20% ~ 80% non-condensing
DIMENSIONS (W x H x D)
물리적(인치/mm): 50.0 x 31.87 x 15.75 / 1271 x 809.45 x 400
Physical w/o Stand (inch / mm): 50.0 x 29.2 x 2.52 / 1271 x 741.8 x 64
포장(inch/mm): 60.12 x 38.78 x 11.02 / 1527 x 985 x 280
WEIGHT
순(lb/kg): 77.38 / 35.1
Net w/o Stand (lb / kg): 68.34 / 31
총중량(파운드/kg): 87.3 / 39.6
What's in the box?
CDM5500T commercial display/Remote Control with batteries/User manual CD wizard/Quick Start Guide/Power Cables/DVI to VGA cable/RS232 cable/RS232 daisy chain cable (2.4mm – 2.4mm)./IR sensor cable/USB cable (Type A-B)
