CDP5560-TL

55” Full HD Multi-touch Commercial Display

갤러리

스펙

표시
패널 크기: 55"
Type/Tech: TFT LCD Module with LED Backlight
표시면적(mm): 1209.6(H) x 680.4 (V) (55” diagonal)
가로 세로 비율: 16:9
기본 해상도: 1920 x 1080
Colors: 1.07 Billion
밝기: 450 nits (typ.)
대비 비율: 1300:1 Typ.
응답 시간: 12ms
보기 각도: H = 178, V = 178 typ.
백라이트 라이프: 30,000 Hours Typ.
표면 처리: Hard coating (3H)
오리엔테이션: Landscape / Portrait
Touch
유형/기술: Optical touch
터치 해상도: 32767 x 32767
터치 포인트: 6-point
INPUT
HDMI: x1
RGB / VGA: x1
디스플레이 포트: x1
DVI: x1
오디오: x1 PC audio(3.5 mm), x1 Shared RCA audio (L+R)
CVBS: x1
YPbPr: x1
RS232: x1
OPS: x1

OUTPUT
DVI: x1
오디오: x1 Shared RCA audio (L+R)
RS232: x1
LAN
RJ45: x1
USB
A형: x1 (for touch)
스피커
10Wx2
COMPATIBILITY
RGB PC/HDMI PC: Refer to timing table
CVBS: 480i,
YPbPr: 480i, 480p,720p,1080i,1080p
HDMI: 480i, 480p,720p,1080i,1080p
디스플레이 포트: 480i, 480p,720p,1080i,1080p
DVI: 480i, 480p,720p,1080i,1080p
CONTROLS
Physical- Top OSD: POWER, MUTE, INPUT, VOL -/+, UP, DOWN, MENU
Brightness, Contrast, Sharpness,Black Level, Tint, Color, Color Temperature, Gamma Selection, Noise Reduction, Film Mode, Picture Reset
Auto Setup, Auto Adjust, H Position, V Position, Clock, Clock Phase, Zoom Mode, Custom Zoom, Input Resolution, Screen Reset
Balance, Treble, Bass, Audio Reset
PIP Mode, PIP Size, PIP Audio, PIP H Position, PIP V Position, SUB Input, PIP Reset
Off Timer, Schedule, Data and Time, Configuration 1 Reset
Language, OSD Turn Off, OSD H Position, OSD V Position, Information OSD, Monitor Information, Monitor ID, IR Control, Tiling, Power on Delay, Closed Caption, Configuration 2 Reset.
Power Save, Heat Status, Screen Saver, Side Border Color, Configuration 3 Reset
Input Change, Terminal Setting, Scan Conversion, Color System, Scan Mode, Serial Control, Lan Setting, APM, Advanced Option Reset, Factory Reset
POWER
전압: 100-240VAC +/- 10% 50/60Hz Wide Range
소비.: 145W (typ), 275W (max)
< 0.5 W ("Off")
ERGONOMICS
Wall Mount (VESA® ): 400 x 400 / 400 x 200 / 200x 200
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
습도: 20% ~ 80% non-condensing
DIMENSIONS
(W x H x D)
Bezel width (B2B): 39 mm
물리적(인치/mm): 49.5x30.3x15.7 / 1257.3 x 770.85 x 400 (w/ Stand)
49.5x28.7x3.1 / 1257.3 x 728.1 x 79.0 (w/o Stand)
포장(inch/mm): 58.0x37.7x11.0 / 1475 x 957 x 279
WEIGHT
순(lb/kg): 94.6 / 43 kg (w/o stand)
99 / 45 kg (w/ Stand)
총중량(파운드/kg): 114.95 / 52.25
패키지 내용물
1. CDP5560-TL display 2. Remote Control with batteries 3. User manual CD wizard 4. Quick Start Guide 5. Power Cables 6. VGA cable 7. RS232 8. USB cable
*Actual content may differ from market to market
