뷰소닉 스마트 디스플레이 VSD220

VSD220

22" (21.5" viewable) 1080p LED Smart Display. Endless Possibilities, One Smart Display.

스펙

SYSTEM
CPU Processor: TI OMAP 4430, Dual-Core ARM? Cortex-A9, 1GHz
운영 체제: Android 4.0 Ice Cream Sandwich
System Memory: LPDDR2 1GB
Storage Memory: 8GB (eMMC4.4)
Internal MIC: Echo cancelling
DISPLAY
유형: 22" (21.5" viewable) Wide Color TFT Active Matrix LED
Display Area: 18.8" horizontal x 10.6" vertical; 21.5" diagonal
Optimum Resolution: 1920x1080
백라이트 라이프: 30,000hrs (min.)
대비 비율: 1000:1 (typ.)
보기 각도: 170º horizontal, 160º vertical
기억
RAM: 1G
FLASH: 8G

Internet Connection
Wireless: WiFi 802.11 b/g/n + Bluetooth V2.1
INPUT/OUTPUT
USB: Type A (x2) and micro USB (x1)
Speakers: 1.5-watt (x2) with SRS 3D Technology
Front Camera: 1.3MP ? HD 720p
COMPATIBILITY
PC: PC compatibles (from VGA up to 1920x1080 non-interlaced)
ERGONOMICS
틸트: 15°~70°
OPERATING CONDITIONS
온도: 32?104º F (0?40º C)
습도: 20?90% (non-condensing)
DIMENSIONS(W x H x D)
Physical: 20.19 x 13.9 x 0.86 in. / 512.8 x 353 x 21.9 mm
Packaging: 23.7 x 17.1 x 5.0 in. / 602 x 435 x 127 mm
WEIGHT
그물: 10.57 lb. / 4.8 kg
징그러워요: 12.78 lb. / 5.8 kg
WALL MOUNT
VESA?: 100 x 100 mm

지원 & 다운로드

데이터 시트

VSD220 데이터 시트

Driver & Software

Standard Monitor Driver Signed Windows 10 x64 Standard Monitor Driver Signed Windows 10 x86 Standard Monitor Driver Signed Windows 7 Standard Monitor Driver Signed Windows 7 x64 Standard Monitor Driver Signed Windows 8 x64 Standard Monitor Driver Signed Windows 8 x86 Standard Monitor Driver Unsigned Windows Standard Monitor Driver Unsigned Windows x64 VSD220 rooted version
