الميزات الرئيسية
  • 163" seamless large screen with high brightness and powerful speakers
  • All-in-One integration for effortless installation
  • Anti-collision, dustproof, and moisture-proof with GOB surface treatment
  • Detachable system control box for a minimalist appearance and easy access
  • Premium aesthetics with an ultra-slim and bezel-free design
  • Capable of PIP/PBP display, wireless casting, and LAN control

LDM163-182
المنتج وصف
The ViewSonic LDM163-182 is a cutting-edge 163” All-in-One LED display designed to elevate visual and auditory experiences in high-end corporate and educational environments. Boasting an impressive 600-nit brightness, a high 6,500:1 contrast ratio, and a 3,840Hz refresh rate, complemented by dual 30W speakers, it ensures exceptional clarity and immersive audio for every video, presentation, or lecture. The All-in-One display features a user-friendly design for a simplified installation experience. It also utilizes the Glue-on-Board (GOB) surface treatment technology, achieving an IP54 rating for enhanced protection from collisions, dust, and moisture. Featuring a 31mm ultra-slim design and 6mm thin bezels, the display offers a premium aesthetic and ensures an engaging viewing experience. Additionally, the detachable control box enables it to achieve a nearly 99% screen-to-body ratio, seamlessly integrating into any space while providing easy accessibility. Moreover, it supports PIP/PBP display and wireless casting capabilities, offering more flexibility for collaboration. Adding to its convenience, compatibility with AV control systems enables IT staff to remotely configure the display.
  1. Speakers
  2. HDMI Out
  3. SPDIF Out
  4. HDMI In*4
  5. LAN
  6. Audio Out*2
  7. IR Interface
  8. Light Sensor
  9. IR Receiver
  10. USB-C
  11. USB-A 3.0
  12. USB-A 2.0
  13. Menu Control: Setting
  14. Menu Control: Enter
  15. Menu Control: Brightness Level
  16. Power Button
  17. Indicator Light
تفضل بزيارة لنا
  • www.viewsonic.com
  • المواصفات
    حجم الشاشة: 163"
    منطقة العرض (مم): 3600 (H) × 2025 (V)
    الدقة الأصلية: 1920x1080
    تقنية اللوحة: Direct view LED
    نوع حزمة LED: SMD 3 in 1 (GOB)
    سلك الربط: Copper
    المسافة بين البكسلات (مم): 1.875
    السطوع (الحد الأقصى): 600 nits (100 levels adjustable)
    نسبة التباين (نموذجي): 6500:1
    درجة حرارة اللون: 3000K -10000K
    الاتجاه: Landscape
    زوايا الرؤية (نموذجي): H = 170, V = 170
    عمر LED (نموذجي): 100,000 Hours
    التخزين المحلي: Total 32GB (26GB available storage)
    نظام التشغيل المدمج: Android 9.0
    الدقة المدعومة: VGA(640 x 480) to 4K(3840 x 2160@60hz)
    التوافق مع HDTV: 480p, 576p, 720p, 1080p, 2160p
    التردد الأفقي: 31K-94kHz
    معدل المسح الرأسي: 56-85Hz
  • الإدخال
    HDMI: 4 (HDMI 2.0/HDCP 2.2) (internal x3, external x1)
    USB Type A: 3 (USB3.0 x1, USB2.0 x2)
    دخل RJ45: 3 (internet x2, control x1)
    دخل الأشعة تحت الحمراء (3.5 مم): 1
    دخل Wi-Fi: 2.4G/5G Hz
    USB Type C: 1 (data only)
  • الإخراج
    خرج HDMI: 1 (HDMI 1.4/HDCP 1.4) (internal x1)
    مكبر الصوت: 30Wx2
    مخرج الصوت (3.5 ملم): 2
    S/PDIF: 1
    USB Type A (طاقة): Shared with USB A input (USB 3.0 5V/0.9A x1, USB 2.0 5V/0.5A x1, USB 2.0 5V/2A x1)
    USB Type C (طاقة): Shared with USB Type C input (5V/1A x1)
  • التحكم
    RJ45 (التحكم عبر LAN): 1(shared with internet)
    USB Type A (للصيانة): 1(shared with USB A input)
    RS232 (DB ذو 9 سنون - أنثى): 1
    مستقبل الأشعة تحت الحمراء: 1
    مستشعر الضوء: 1
  • أخرى
    جهد مصدر الطاقة: 100-240V ~ 50/60Hz (vary by country)
    استهلاك الطاقة (واط/وحدة): 919W (typ), 2642W (max) < 0.5W (Hibernate)
    تبديد الحرارة (BTU/ساعة): 3136 (typ), 9015 (max)
    تبديد الحرارة لكل وحدة مساحة (BTU/ساعة/م²): 430.1 (typ), 1236.6 (max)
    درجة حرارة التشغيل: 0~40℃
    إجمالي عدد وحدات LED: 144
    تصنيف الحماية من الدخول (IP): IP54(Front)
    تصنيف الحماية من الصدمات (IK): IK06(Front)
    الوزن الصافي (بدون حامل الحائط): 382.28 lbs (173.4 kg)
    الوزن الصافي (مع حامل الحائط): 419.32 lbs (190.2 kg)
    الوزن الإجمالي: 725.32 lbs (329 kg)
    أبعاد المنتج (العرض × الارتفاع × العمق): 142.2 x 85.47 x 1.2 inches (3612 x 2171 x 31 mm)
    أبعاد المنتج (العرض × الارتفاع × العمق) مع حامل الحائط: 142.2 x 85.47 x 2.1 inches (3612 x 2171 x 53 mm)
    Packing Dimensions (WxHxD): 88.58 x 48.81 x 39.37 inches (2250 x 1240 x 1000 mm)
  • الملحقات القياسية
    صندوق التحكم: 1
    سلك الطاقة: 1
    كابل LAN (Cat 5E): 1
    كابل تمديد الأشعة تحت الحمراء: 1
    جهاز التحكم عن بُعد: 1(Bluetooth & IR)
    دليل التركيب: 1
    التثبيت على الحائط: 1
    قطع الغيار: LED module x10 3 in 1 hub board x1
    أداة الصيانة: LD-MK-004 x1 LD-MK-006 x1
  • الملحقات الاختيارية
    أداة الصيانة: LD-MK-004 LD-MK-006
    حامل أرضي: LD-STND-009
