VG2427wm

61cm / 24" (23.6" VIEWABLE) WIDESCREEN LCD WITH FULL HD RESOLUTION

GALERIE

RECENZII

What Laptop, UK.

“Awarded to VG2427wm
Widescreen Monitor Group Test
What Laptop Gold Award”

“Awarded to VG2427wm
Widescreen Monitor Group Test
What Laptop Gold Award ”

“Awarded to VG2427wm
Widescreen Monitor Group Test
What Laptop Gold Award”

SPECIFICAȚII

COLORS
Black
LCD
Rată de contrast: 1000:1(typ.) ; 20000:1 dynamic
Unghiuri de vizualizare: 170o(H), 160o(V) at 10:1 c/r, 170o(H), 170o(V) at 5:1 c/r
Luminozitate: 300 cd/m² (typ.)
Display Area: 521mm (H) x 293mm (V)
Optimum Resolution: 1920×1080
Timp de răspuns: 5ms(typ.)
Sursă de lumină: 50,000 hrs(typ.)
Panel Surface: Anti-Glare
Pixel Pitch: 0.2715mm(H)×0.2715mm(V)
Colour Support: 16.7 M(6-bits + Hi FRC)
Size: 60 cm (23.6") wide Color TFT Active Matrix LCD with 16:9 aspect ratio
COMPATIBILITY
PC: VGA up to 1920×1080 non-interlaced
Mac®: Power Mac, up to 1920×1080

DIMENSIONS
Physical With Stand: 564mmx442mmx250mm(22.2"x17.4"x9.8")
Physical Without Stand: 564mmx335mmx67mm(22.2"x13.2"x2.6")
CONȚINUT PACHET
D-Sub Cable, DVI-D Cable, Power Cable, Audio cable, USB cable
AUDIO
Difuzor: 2x2 watt
INPUT
Sync: H/V Separated
Digital: DVI-D(TMDS, 100ohms)
Analogue: RGB Analog (75 ohms, 0.7/1.0 Vp-p)
Frequency: Fh: 22-82kHz, Fv: 50-75Hz
CONNECTOR
Analogue: 15 pin mini D-sub×1
Digital: DVI-D
Putere: Built-in power Adapter, 3-Pin plug
USB: down stream x2 / up stream x1
Audio: 3.5 mm Audio in
POWER
Voltaj: AC 100-240V(Universal); 50/60Hz(Switch)
Consum: 45(typ.)
Eco Mode: optimize 31W(typ.)/conserve 26W(typ.)
Save mode: ≦1W
CONTROLS
Basic: Power, Mute,[1], Up[▲], Down[▼], [2]
On View (PC mode): Auto image adjust, Contrast/Brightness, Audio adjust: Volume, mute,
Color adjust: sRGB, 9300K, 7500K, 6500K, 5000K, user color [R, G, B]
Information, Manual image adjust: H/V position, Horizontal size, fine tune, sharpness, dynamic contrast, aspect ratio, Eco mode, Setup menu: Language select, resolution notice, OSD position, OSD timeout, OSD background, memory recall
OPERATING CONDITIONS
Temperatură: 32-104°F(0-40°C)
Umiditate: 10-90%(Non condensed)
WEIGHT
Masă: 7 kg(15.4 lb)
Greutate: 9.6 kg(21.2 lb)
POWER MANAGEMENT
TCO'03, ENERGY STAR®
VESA MOUNT COMPLIANT
VESA® 100mmx100mm
ERGONOMICS
Înclinare: 20˚~-5˚
Pivotant: 360˚(180 ˚left / 180 ˚right)
Height Adjustment: 0~135mm
