CD4220

LCD display, 1.8m power cables (Europe [Schuko]/UK), remote control, batteries, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)

Speakers: 2 x 7 watt with SRS TruSurround¹

Audio Out: 1 x 3.5mm mini stereo

2 x RCA (left/right)
Composite Video Input: 1 x RCA (CVBS)

1 x BNC (CVBS)
Component Video Input: 3 x BNC (YPbPr/YCbCr)
Audio Input: 1 x 3.5mm mini stereo

2 x RCA (left/right)
Analogue-In: 1 x 15-pin mini D-Sub (detachable cable)
Analogue-Out: 1 x 15-pin mini D-Sub (detachable cable)
Composite Video Output: 1 x BNC (CVBS)
Живлення: 1 x 3-pin plug
Control/Net-Out: 1 x 9-pin mini D-sub RS-232
Control/Net-In: 1 x 9-pin mini D-sub RS-232
Digital-In: 1 x HDMI (with HDCP)

Напруга: AC 100–240V (universal), 50/60Hz
Споживання: <246 watt, <5 watt in power save mode

Basic: Power, menu, exit, source, up/down, volume, mute, main power switch
OSD: Picture Menu (brightness, contrast, sharpness, black level, NR, tint, colour, colour temperature, colour User-RGB, picture reset),
Screen Menu (H/V position, H size, fine tune, zoom [H&V zoom, H zoom, V zoom, H/V zoom position], screen reset),
Audio Menu (balance, treble, bass), PIP Menu (PIP size, PIP audio source, PIP reset),
Configuration Menu (auto setup, auto adjust, power save, OSD language, screen saver, colour TV system, OSD turn off, information OSD, off timer, OSD H/V position, display information, config. reset),
Advanced Menu (input resolution, black level expansion, Gamma, scan mode, scan conversion, film mode, remote control, display ID, tiling [H/V monitors, position, frame compensation, enable], power on delay, date/time, auto on/off scheduler [day, hour, minute, input], monitor ID, DDC/CI, sync type, advanced reset)

Температура: 0°C–40°C landscape mode, 5°C–35°C portrait mode
Вологість: 20%–80% (non-condensing)

Нетто: 29.9kg (w/o stand, w/o speakers), 31.7kg (w stand, w/o speakers)
Брутто: 34.7kg

Frequency: Fh: 15.6kHz, 15.7kHz, 31-91kHz, Fv: 50-75Hz
Sync: H/V separate (TTL), composite, sync on green
Analogue: RGB analogue (0.7/1.0 Vp-p, 75 ohm), PAL, SECAM, NTSC, SDTV/EDTV (480i/p, 576i/p), HDTV (720p, 1080i)
Digital: HDMI (HDCP enabled; TMDS, 100 ohm)

VESA FDMI 400mm x 200mm, M6 screws
